Archive for the ‘Banana Pi’ Category

Banana Pi BPI-M1/M1/R1 – Debian 10 buster mate desktop with grub support

Samstag, Dezember 26th, 2020

Banana Pi BPI-M1/M1/R1 – Debian 10 buster mate desktop with grub support

root@bpi-iot-jsho-tools-21:~# armbian-config

motionEyeOS – building from source

Freitag, Dezember 25th, 2020

If you want to compile the latest GIT version you need a computer running Linux any recent distro should work. Follow the steps below to download, compile and prepare the image from the GIT repo. Replace [board] with your actual board’s name (e.g. raspberrypi)

https://github.com/ccrisan/motioneyeos/wiki/Building-From-Source

# git clone –depth 1 https://github.com/ccrisan/motioneyeos.git motioneyeos
# cd motioneyeos
# ./build.sh [board] xconfig
# ./build.sh [board]
# ./build.sh [board] mkimage

https://github.com/ccrisan/motioneyeos/wiki/Supported-Devices

Banana Pi BPI-M5 – eine neue Alternative zum Raspberry Pi bringt eMMC-Speicher

Dienstag, Dezember 15th, 2020

Banana Pi BPI-EAI80 AIoT – ist ab sofort für knapp € 14 erhältlich

Sonntag, Oktober 11th, 2020

Banana Pi BPI-M2 Zero – Quad Core Cortex-A7 with 512B RAM, WiFi, Bluetooth

Sonntag, März 8th, 2020

Banana Pi – with 24core ARM Cortex A53 Processor and 32GB RAM

Donnerstag, Dezember 27th, 2018

Project Linux Embedded Development Environment LEDE 17.01.2 – is a Linux operating system based on OpenWrt

Dienstag, Oktober 3rd, 2017

BananaPi_Routerboard_01



The default IP@ of the LAN ports of a LEDE device is 192.168.1.1 if the addresses of the devices in the network you connect to the WAN port are 192.168.1.X (X=any number) you need to change the IP@ of the LAN interfaces your LEDE router to 192.168.2.1 or to something that isn’t 192.168.1.X

# uci set network.lan.ipaddr=’new-ip-address‘
# uci commit && service network restart

UCI (Unified Configuration Interface) – Technical Reference





OpenWrt 15.05.1 – with Banana Pi Router BPI-R1

Sonntag, Oktober 1st, 2017

   OpenWrt – is an open source project for embedded operating system based on Linux, primarily used on embedded devices to route network traffic

BananaPi_Routerboard_01

Banana Pi M2 Berry – mit einem echten SATA-Anschluss ohne langsame USB-zu-SATA-Brücke

Sonntag, September 10th, 2017

Banana PI BPI-M1 – die Betriebstemperatur CPU auslesen mit OS Raspbian

Samstag, März 25th, 2017
# cat /sys/devices/platform/sunxi-i2c.0/i2c-0/0-0034/temp1_input
# 50600

Das sind 1/1000 Grad wenn man die Zahl also durch 1000 teilt haben wir die Temperatur in Grad – hier 50,6°

Banana Pi – cannot connect with PuTTY SSH

Dienstag, Mai 24th, 2016

Make sure your SSH client is not too old. (PuTTY >= 0.63)

PuTTY_01

Banana Pi M2 – Quad Core Board mit WiFi-Chip

Mittwoch, März 25th, 2015

Banana_Pi_M2_01

WiringPi – GPIO Interface library for the Banana Pi

Sonntag, Februar 1st, 2015

BananaPI_logo   WiringPi includes a command-line utility gpio which can be used to program and setup the GPIO Pins – you can use this to read and write the pins and even use it to control them from shell scripts

# cd /usr/local/bin
# git clone https://github.com/LeMaker/WiringBPi.git
# cd /usr/local/bin/WiringBPi
# chmod +x build
# ./build
# gpio readall

WiringPi_01

FHEM server – Raspberry Pi acts as home automation server

Samstag, Januar 24th, 2015

FHEMlogo   raspberrypi_logo.jpg   FHEM server is used to automate some common tasks in the household like switching lamps / shutters / heating / etc. and to log events like temperature / humidity / power consumption

FHEM_00

Munin – is a networked resource monitoring tool that can help analyze resource trends

Dienstag, Dezember 30th, 2014

Munin_logo   Munin the monitoring tool surveys all your computers and remembers what it saw. It presents all the information in graphs through a web interface. Its emphasis is on plug and play capabilities. After completing a installation a high number of monitoring plugins will be playing with no more effort

Munin_01
